Overview
Mining and heavy industrial sites represent the most severe operating environment for electrical equipment. Open-pit mines, underground coal mines, mineral processing plants and crushing workshops are characterized by heavy dust, high humidity, intense mechanical vibration, frequent load impacts and severe voltage fluctuations. Power distribution equipment for mining applications must deliver high robustness, reliable dustproof, moisture-proof, anti-corrosion and explosion-proof performance to sustain stable, continuous and safe operation under extreme harsh working conditions. QDTB® provides a complete range of power equipment specifically engineered for mining and heavy industrial applications.
Surface Heavy-Duty Transformers
S13-M, S15-M fully sealed oil-immersed transformers with corrugated oil tank structure achieving complete dustproof, rainproof and moisture-proof performance. Reinforced insulation structure effectively resists mining voltage surges and operational overvoltage.
Underground Flame-Proof Substations
KBSGZY mining flame-proof mobile substations with Ex d I Mb explosion-proof grade. 10kV input with 1140V/660V output specially customized for underground mining heavy equipment. Integrated protection with overload, short-circuit and leakage functions.
Anti-Dust Dry-Type Transformers
SCB13, SCBH15 epoxy resin cast dry-type transformers with IP44 high protection grade preventing fine mineral dust penetration. Flame-retardant and non-combustible properties meet stringent fire safety standards for mining workshops.
Power Quality Optimization
Intelligent reactive power compensation cabinets and APF active filters stabilize power factor above 0.95, suppress 3rd, 5th and 7th harmonics from crushers and ball mills, eliminating equipment overheating and grid metering losses.
Mining Power System Calculator
Size the power distribution for your mine - crusher, hoist, fan and conveyor loads, motor-starting voltage-dip check, VFD harmonic filtering and altitude derating, with BOM and single-line diagram.
Industry Context & Operational Characteristics
Mining and heavy industrial sites represent the most severe operating environment for electrical equipment. Open-pit mines, underground coal mines, mineral processing plants and crushing workshops are typically characterized by heavy dust, high humidity, intense mechanical vibration, frequent load impacts and severe voltage fluctuations. Power distribution equipment for mining applications must deliver high robustness, reliable dustproof, moisture-proof, anti-corrosion and explosion-proof performance to sustain stable, continuous and safe operation under extreme harsh working conditions.
Key Operational Challenges
Power Distribution Architecture
35kV/10kV external grid → Main mine substation → Workshop distribution & underground central substation → Mobile mining substation → Terminal heavy-duty equipment
Core Equipment Selection
Surface Heavy-Duty Oil-Immersed Transformers
Recommended Model: S13-M, S15-M fully sealed oil-immersed power transformers
Core Configuration & Advantages
- First-class energy efficiency design, maintaining stable output under long-term continuous heavy-load operation
- Full-sealed corrugated oil tank structure achieving complete dustproof, rainproof and moisture-proof performance
- Reinforced insulation structure that effectively resists mining voltage surges and operational overvoltage
- Equipped with comprehensive monitoring accessories, including oil level gauges, pressure relief valves and temperature sensors
- Custom high-altitude and anti-corrosion versions available for special mining geographical conditions
Applications: Mineral processing plants, crushing workshops, tailings pump stations and surface industrial zones.
Indoor Anti-Dust Dry-Type Transformers
Recommended Model: SCB13, SCBH15 epoxy resin cast dry-type transformers
Core Configuration & Advantages
- IP44 high protection grade that prevents fine mineral dust from penetrating coil windings
- Integral epoxy casting structure with excellent vibration resistance and anti-condensation performance
- Flame-retardant and non-combustible properties that meet stringent fire safety standards for mining workshops
- Built-in forced air cooling system with strong overload capacity to adapt to peak mining power demand
Applications: Central control rooms, indoor distribution rooms and auxiliary workshop power supply systems.
Underground Flame-Proof Mobile Substation
Recommended Model: KBSGZY mining flame-proof mobile substation
Core Configuration & Advantages
- 10kV input with 1140V/660V output, specially customized for underground mining low-voltage heavy equipment
- Ex d I Mb professional mining explosion-proof grade compliant with underground safety regulations
- Integrated high-low voltage switch and transformer unit with complete overload, short-circuit and leakage protection functions
- Movable base design with anti-shock and anti-tilt performance, adapting to advancing mining working faces
Applications: Underground shearers, roadheaders, scraper conveyors and underground drainage systems.
Harmonic Suppression Reactors & Isolation Transformers
Recommended Model: CKSC series dry-type reactors & industrial isolation transformers
Core Configuration & Advantages
- CKSC series dry-type reactors effectively suppress severe harmonic pollution generated by mining frequency conversion equipment
- Industrial isolation transformers provide stable, safe and interference-free power supply
- Designed for underground monitoring, communication and lighting systems
- Comprehensive harmonic filtering solutions for mining power grids
Switchgear & Substation Selection
High & Low Voltage Switchgear
KYN28A-12 high-voltage switchgears and GCD/GCS mining low-voltage switchgears adopt enhanced dustproof, anti-vibration and anti-condensation designs, ensuring long-term stable operation in complex mining industrial zones.
Outdoor Mining Box-Type Substation
ZBW/ZGS outdoor prefabricated substations are deployed in remote dumping sites, temporary mining areas and tailings fields. Featuring integrated design, anti-corrosion shell and automatic dehumidification systems, the equipment supports rapid on-site deployment without large-scale civil construction.
Underground Explosion-Proof Switch Equipment
PJG high-voltage explosion-proof distribution devices and QBZ/BKD low-voltage flame-proof switches support gas-electric and wind-electric interlock functions, establishing comprehensive safety guarantees for underground mining operations.
Mining Harsh Environment Customized Enhancement
Dust & Moisture Prevention
All cabinet units equipped with automatic heaters and dehumidifiers; fully sealed coil structure to block dust and moisture invasion
Anti-Vibration Reinforcement
Reinforced transformer core compression and flexible busbar connection to prevent loose components caused by long-term vibration
Multi-Layer Anti-Corrosion
Epoxy zinc-rich primer and weather-resistant finish coating for outdoor mining equipment against chemical corrosion
High-Altitude Adaptation
Derating optimization and enhanced heat dissipation structure designed for plateau mining environments
Explosion Classification Design
Standard protection for open-pit mines and full Class I explosion-proof configuration for coal and gas-rich mines
Power Quality Optimization
Impact loads such as crushers and ball mills commonly cause low power factor and severe harmonic distortion in mining power systems. We deploy intelligent reactive power compensation cabinets and APF active filters to stabilize the power factor above 0.95, suppress 3rd, 5th and 7th harmonics, and eliminate equipment overheating and grid metering losses.
Key Benefits
Full Extreme Environment Adaptability
Targeted structural and performance design tailored for mining dust, humidity, vibration and corrosion scenarios
Complete Product Coverage
Integrates surface, indoor and underground explosion-proof power equipment for one-stop full-scene matching
Strong Impact & Harmonic Resistance
Effectively resolves typical power quality hazards in heavy mining production
High Safety & Low Failure Rate
Professional mining explosion-proof and reinforced protection design for ultra-safe operation
Long-Term Operational Stability
Fully adaptable to 24/7 continuous high-load production of mining enterprises
Technical specifications
| Transformer Capacity | 100 kVA - 3,150 kVA |
| Voltage Levels | 35kV / 10kV / 6kV → 1140V/660V/400V |
| Explosion-Proof Grade | Ex d I Mb (underground) |
| Protection Rating | IP44 (indoor) / IP54 (outdoor) |
| Insulation Class | F / H (155°C / 180°C) |
| Ambient Temperature | -25°C to +55°C (high-altitude available) |
| Anti-Vibration | Reinforced core & flexible busbar |
| Corrosion Protection | Epoxy zinc-rich primer + weather-resistant finish |
Standards Compliance
Applications
