Renewable energy projects such as photovoltaic power stations and wind farms are commonly constructed in remote suburbs, mountainous regions, coastal zones and wilderness areas. These sites feature harsh open-air operating conditions including strong winds, high humidity, intense ultraviolet radiation and extreme temperature differences. Wind and solar power generation exhibit inherent intermittency and fluctuation, placing high requirements on equipment environmental adaptability, operational stability and power quality regulation capability. QDTB® provides comprehensive power equipment solutions for the new energy sector.
Step-Up Oil-Immersed Transformers
S13, S20 series outdoor fully sealed transformers with anti-aging design resistant to wind, rain, sand and UV erosion. Superior anti-fluctuation capability for intermittent generation impacts.
Amorphous Alloy Efficiency
SBH15/SBH21 amorphous alloy transformers with ultra-low no-load loss, highly suitable for new energy stations with long-term standby and fluctuating loads. Maximizes investment return rates.
Grid-Connected Substations
Customized ZGS/ZBW box substations integrating boost transformation, grid-connected switching and reactive power compensation. Specially developed for centralized PV and wind farm grid connection.
Power Quality Equipment
CKSC/BKSC reactors suppress grid-connected harmonics and voltage flicker from power fluctuations, stabilizing grid-connected power quality to meet international grid-connection standards.
Renewable Energy Hybrid Configurator
Configure a wind + solar + battery hybrid plant - capacity matching and complementarity analysis, P50/P90 energy and full-cost LCOE, with a priced equipment BOM.
Industry Context & Operational Characteristics
Renewable energy projects such as photovoltaic power stations and wind farms are commonly constructed in remote suburbs, mountainous regions, coastal zones and wilderness areas. These sites feature harsh open-air operating conditions, including strong winds, high humidity, intense ultraviolet radiation and extreme temperature differences. In addition, wind and solar power generation exhibit inherent intermittency and fluctuation, placing high requirements on equipment environmental adaptability, operational stability and power quality regulation capability.
Key Operational Challenges
Power Distribution Architecture
PV/Wind power generation unit → Combiner box → Step-up transformer → Grid-connected switchgear → Public power grid
Core Equipment Selection
Photovoltaic & Wind Power Step-Up Oil-Immersed Transformer
Recommended Model: S13, S20 series outdoor fully sealed oil-immersed transformers
Core Configuration & Advantages
- Outdoor full-sealed anti-aging design resistant to wind, rain, sand and ultraviolet erosion
- Superior anti-fluctuation capability to adapt to intermittent wind and solar power generation impacts
- Low-loss and high-efficiency operation that improves new energy grid-connection power generation efficiency
- Long service life and maintenance-free performance suitable for unattended power station operation
Amorphous Alloy Energy-Saving Transformer
Recommended Model: SBH15/SBH21 series amorphous alloy transformers
Core Configuration & Advantages
- Ultra-low no-load loss for maximum energy efficiency
- Highly suitable for new energy power stations with long-term standby and fluctuating loads
- Effectively reduces comprehensive power generation losses
- Improves project investment return rates
Switchgear & Substation Selection
Outdoor Prefabricated Substation for New Energy
Customized ZGS/ZBW new energy step-up box substations integrate boost transformation, grid-connected switching and reactive power compensation functions. Specially developed for centralized grid connection of PV and wind farms, the equipment features outdoor anti-corrosion, anti-aging and wide temperature adaptive performance.
Reactors & Power Quality Equipment
CKSC/BKSC series dry-type reactors suppress grid-connected harmonics and voltage flicker caused by new energy power fluctuations, stabilize grid-connected power quality and fully meet international grid-connection standards.
High & Low Voltage Switchgear
KYN/XGN high-voltage switchgears and GCS/MNS low-voltage switchgears adopt enhanced anti-condensation and anti-corrosion designs, adapting to long-term unattended operation of new energy power stations.
New Energy Scenario Customization
Wide Temperature Adaptation
Customized solutions for high-temperature deserts, severe cold plateaus and humid coastal areas
Anti-Fluctuation Design
Enhanced electrical tolerance for intermittent new energy power generation
Unattended Reliability Upgrade
Optimized low-failure structure with remote monitoring and early warning functions
Coastal Salt Spray Corrosion Resistance
Special anti-salt spray coating for offshore wind and coastal PV projects
Power Quality Optimization
Power quality is vital for renewable energy systems. QDTB® equipment is equipped with both passive and active harmonic filtering systems, combined with automatic reactive power compensation cabinets. This solution stabilizes voltage, minimizes total harmonic distortion (THD), and improves power factor, ensuring compliance with national grid regulations and protecting equipment from damage caused by poor power quality.
Key Benefits
Extreme Environment Adaptability
Fully compatible with various complex outdoor new energy application scenarios
Stable Grid Connection
Effectively suppresses new energy power fluctuations and harmonic interference
High Power Generation Efficiency
Ultra-low loss equipment maximizes power generation economic benefits
Low Operation Cost
Maintenance-free design reduces manual operation and maintenance costs for unattended power stations
Technical specifications
| Transformer Capacity | 100 kVA - 3,150 kVA |
| Voltage Levels | 35kV / 10kV → 0.27-0.8kV (PV) / 0.69kV (Wind) |
| Energy Efficiency | S13/S20 / SBH15/SBH21 |
| Insulation Class | F / H (155°C / 180°C) |
| Protection Rating | IP54 (outdoor substation) |
| Temperature Range | -40°C to +55°C (wide adaptation) |
| Anti-Corrosion | Salt-spray resistant for coastal projects |
| Design Life | 25+ years (unattended operation) |
Standards Compliance
Applications
Related Products
Explore QDTB® product lines available for this solution
Oil Immersed Transformers
S13/S20 outdoor step-up transformers for PV and wind power stations
Amorphous Alloy Transformers
SBH15/SBH21 ultra-low loss transformers for new energy efficiency
Box-Type Substations
ZGS/ZBW new energy step-up substations for centralized grid connection
High Voltage Switchgear
KYN/XGN for new energy power station protection and switching
Low Voltage Switchgear
GCS/MNS for auxiliary power distribution in renewable stations
Reactors
CKSC/BKSC for harmonic suppression and grid quality stabilization
Why Choose QDTB® for Renewable Energy
One-Stop Supply of Conventional & Solar Power Equipment
From power distribution system design to solar energy — transformers, switchgear, substations and solar equipment, sized and quoted in one place. Use our calculators to get a complete bill of materials and FOB price.
