Overview
QDTB® delivers specialized transformer and substation solutions engineered specifically for wind power applications. Our wind-duty equipment features enhanced insulation systems designed for variable frequency operation from wind turbine generators, anti-corrosion protection for harsh offshore environments, and extended temperature range components that perform reliably in extreme climates from arctic cold to desert heat. With proven installations in wind farms across 30+ countries, our equipment ensures maximum availability and minimum downtime for your wind energy investment.
Variable Frequency Ready
Enhanced insulation systems designed to handle the variable frequency output (0.5-60Hz) from wind turbine generators, with reinforced turn-to-turn and layer insulation to withstand voltage transients from frequency converters.
Offshore Rated
Marine-grade corrosion protection with C5-M coating systems, stainless steel hardware, IP55+ enclosures, and special winding treatments that resist salt spray, humidity, and UV degradation in offshore wind farm environments.
Extreme Climate Operation
Components rated for -40°C to +65°C ambient operation with special core steel, cold-temperature insulation fluids, and heater systems that ensure reliable starting and operation in arctic and tropical conditions.
Grid Code Compliance
Integrated solutions that meet grid code requirements for wind farms, including reactive power capability, fault ride-through support, and harmonic filtering to ensure stable grid connection.
Wind Farm Box Transformer Calculator
Size the box-type step-up transformers for your wind turbines with voltage class, reactive compensation and a complete bill of materials.
Industry Context & Operational Characteristics
Wind power projects are mainly deployed in inland mountainous areas, coastal wind fields and offshore wind farms, featuring extremely harsh outdoor operating conditions. Wind power generation has strong randomness and volatility with frequent wind speed changes, resulting in severe voltage impact and frequency fluctuation on grid-connected equipment. Wind power dedicated power equipment needs to withstand strong wind vibration, salt spray corrosion, extreme temperature difference and variable frequency operation, with high insulation reliability and grid-adaptive performance to guarantee long-term stable grid-connected power generation.
Key Operational Challenges
Power Distribution Architecture
Wind turbine generator → Turbine step-up transformer → Collection substation → Main step-up substation → Public power grid
Core Equipment Selection
Wind Turbine Step-Up Transformers
Recommended Model: S13/S20 series wind power dedicated fully sealed transformers
Core Configuration & Advantages
- Enhanced insulation system specially designed for variable frequency operation of wind turbines, resisting overvoltage and insulation aging
- Strong anti-fluctuation and anti-impact capability to adapt to random wind power output changes
- Full-sealed waterproof and dustproof structure, suitable for long-term outdoor wind field operation
- Ultra-low loss design to reduce power generation loss and improve wind power grid-connected efficiency
Applications: Onshore and offshore single wind turbine step-up power supply.
Wind Farm Collection Station Transformers
Recommended Model: Large-capacity high-efficiency oil-immersed power transformers
Core Configuration & Advantages
- Used for centralized power collection and secondary step-up of wind farms
- Large overload margin, stable voltage regulation and strong short-circuit resistance
- Can bear superposition fluctuation of multiple wind turbine outputs
- Ensures stable centralized grid connection of wind farm power
Applications: Wind farm centralized power collection and step-up substations.
Offshore Special Anti-Corrosion Transformers
Recommended Model: Customized offshore wind power dedicated transformers
Core Configuration & Advantages
- Multi-layer salt spray anti-corrosion coating
- Closed anti-condensation system
- Marine-grade aging-resistant components
- Effectively resists high-humidity and salt spray erosion of marine atmosphere
Applications: Offshore wind farm projects requiring marine-grade corrosion protection.
Switchgear & Substation Selection
Wind Farm Collection Substation
Integrated wind power collection substations realize centralized power collection, voltage regulation and reactive power compensation of wind turbine units. With wind power-specific protection logic, it can quickly isolate fault units and ensure overall stable operation of wind farms.
Wind Power Dedicated Power Quality Equipment
Customized reactors, SVG reactive power compensation and harmonic filtering devices target wind power voltage flicker, reactive power fluctuation and harmonic problems, stabilizing wind farm grid-connected power factor and power quality.
Wind-Proof and Vibration-Proof Switchgear
High and low voltage switchgears adopt reinforced anti-vibration structure and anti-condensation design, adapting to strong wind vibration environment of wind fields and ensuring reliable switching and protection operation.
Wind Power Scenario Customization
Variable Frequency Insulation Upgrade
Special insulation structure to resist variable frequency overvoltage and extend equipment service life
Offshore Salt Spray Resistance
Marine-grade anti-corrosion coating and fully sealed anti-moisture structure for offshore wind farms
Low Temperature Adaptation
Low-temperature resistant oil and structural optimization for alpine wind farm anti-freezing operation
Wind Vibration Reinforcement
Reinforced core and fastening structure to resist long-term strong wind vibration
Remote Intelligent Monitoring
Equipped with full-state monitoring system for unattended wind farm operation management
Power Quality Optimization
Wind power voltage flicker, reactive power fluctuation and harmonic problems are addressed through customized reactors, SVG reactive power compensation and harmonic filtering devices, stabilizing wind farm grid-connected power factor and power quality.
Key Benefits
Professional Wind Power Adaptability
Targeted design for wind power volatility, variable frequency load and harsh wind field environment
Onshore & Offshore Full Coverage
Complete equipment solutions for inland and offshore wind power projects
Stable Grid Connection & Low Loss
Effectively suppresses wind power grid-connected fluctuation and reduces power generation loss
Extreme Environment Durability
Anti-corrosion, anti-vibration and anti-aging design ensures long-term reliable operation
Intelligent O&M Support
Matches unattended wind farm management mode and reduces operational costs
Technical specifications
| Capacity Range | 100 kVA - 8,000 kVA |
| Voltage Range | Up to 66kV (offshore) / 35kV (onshore) |
| Frequency Range | 0.5Hz - 60Hz (variable) |
| Insulation Class | H (180°C) / C (220°C) for nacelle |
| Protection Rating | IP54 (onshore) / IP65 (offshore) |
| Corrosion Category | C3 (onshore) / C5-M (offshore) |
| Temperature Range | -40°C to +65°C ambient |
| Lifetime | 25+ years (wind farm duty) |
Standards Compliance
